INDUSTRIAL, ACOUSTIC, THERMAL
COMPOSITE BARRIER
TABS
STUDIO 50
Specialist chain stitched composite that maintains a consistent 50mm slab depth through stitch technology
This innovative composite is unique in that additional layers and materials can be incorporated to point load performance and to integrate with each unique interior. This means that acoustic insulation, absorption and thermal resistance can be enhanced to match a clients individual specifications. The composite can be further customised to be fully demountable and reusable with a patented jointing system to ensure the best acoustic seal between barriers.
In addition to excellent acoustic and thermal characteristics
TABS STUDIO 50 also offers integral condensation, vapour,
radiant and smoke barriers.
R VALUE:
1.55 M2K/W
DIMENSIONS:
1.220MM X UNLIMITED MM X 50MM
PERFORMANCE:
αw 1.0 CLASS A
15 dB Rw STANDARD
25 dB Rw 2x GLASS LAYERS
27 dB Rw 3x GLASS LAYERS
WEIGHT
:
1.83 Kgm2 STANDARD
3.83 Kgm2 2x GLASS LAYERS
4.83 Kgm2 3x GLASS LAYERS
INDUSTRIAL OPEN WEAVE SURFACE FINISH
-BLACK- GREY- WHITE STOCK COLOURS
-RAL COLOURS AVAILABLE ON REQUEST
RANGE OF BACKING MATERIAL OPTIONS
-ALUMINIUM PAPER
-FR POLYESTER
-FR POLYESTER WITH LAMINATED PVC
-PVC
RESILIENT STRING SURFACES
INDUSTRIAL DESIGN
CHAIN STITCHED COMPOSITE
HEAVY DUTY CONSTRUCTION
FR POLYESTER FIBROUS CORE
RANGE OF DENSITIES
ROCKWOOL-GLASS WOOL CORE AVAILABLE
ALL MATERIALS UK/EU ORIGIN
INSTALLED VERTICALLY, HORIZONTALLY
OR ON A PITCH
MACHINE FINISHED ROLL ENDS
CLASS A SOUND ABSORPTION
αw = 1.0 (UNI EN ISO 354:2003)
αw = 1.0 (BS EN ISO 11654:1997)
SRI 15 dB Rw
STANDARD PRODUCT
(UNI EN ISO 10140-2:2021)
SRI 25 dB Rw
2x LAMINATED 1KG GLASS LAYERS
(UNI EN ISO 10140-2:2021)
SRI 27 dB Rw
3x LAMINATED 1KG GLASS LAYERS
(UNI EN ISO 10140-2:2021)
THERMAL RESISTANCE 1.55 m2K/W
(UNI EN ISO 12667:2002)
THERMAL CONDUCTIVITY 0.045 W/mK
(UNI EN ISO 12667:2002)
B-s1,d0 FIRE PERFORMANCE
(BS EN ISO 13501-1:2018)
B-s1,d0 FIRE PERFORMANCE
(UNI EN ISO 13823:2020)
B-s1,d0 FIRE PERFORMANCE
(UNI EN ISO 13501-1:2019)
A1 FIRE CLASS OPTION
INSULATION GRAPH
ABSORPTION GRAPH
STANDARD CLASS A COMPOSITE
SPECIALIST VELCRO FASTENING SYSTEM
STANDARD CLASS A COMPOSITE
SPECIALIST VELCRO FASTENING SYSTEM INTERNAL HEAVY LAYERS (2)
